PCB Terminal Block 18P 3.5mm

Sanan Electronics Co., Ltd. is a manufacturer specializing in researching new products, mass-producing and selling goods with brands. As the professional manufacture, we would like to provide you PCB Terminal Block 18P 3.5mm. And we will offer you the best after-sale service and timely delivery. With the development of market,our company has accumulated rich experience in researching and producing insertion parts. The three main series of the products containing electronic connectors, PCB Terminal Block ,DIN rail enclosure, IO modeules. Currently, our company gets the certification of ISO9001 again, and our products also get the authentication of Europe CE, America UL, and Europe RoHS. Surviving in the current international situation filled with opportunity and challenge, we are improving the technology, normalizing the management, consummating the methods of measure and our fame is also broadening. Now we own nearly one thousand clients and the products have been sold to the countries including Europe and Southeast Asia.Our company pays more attention on the innovation management, and the tenet of the company lies in creating a harmonious situation with the related people and things. Self-discipline and social commitment would embrace everything.

Model:SA212-3.5-18P

Send Inquiry

Product Description

PCB Terminal Block 18P 3.5mm Product introduction

There are multiple kinds of terminal blocks , they all provide the same function of connecting electronical components in a safe, reliable manner,ideal for a variety of industrial control, automation, and test equipment applications,PCB terminal block is a tool used to safety connect two or more wires together, once the wires are properly arranged within a terminal block, current will be able to flow between the incoming and outgoing sources, terminal blocks promote the industry automation.

Feature

●Easy to use,no need to weld, handy and easy to assemble,solder in easily and tighten very well on the terminated wires, spiral wire is not easy to take off the line.
●Wide application, the terminal blocks is ideal foe small electronic watches, calculator, general computer, communication electronics device and other electronic equipment.
●Universal installation method, suitable for various situations
●PA66 material, sturdy, high temperature resistance, flame retardant.

Product specification of PCB Terminal Block 18P 3.5mm

Product name PCB terminal block
Material Plastic / copper
Color Black
Contact Form 2P-20P(accept customization )
AWG 28~14AWG
Strip length 8mm
Rated voltage 300V 12A UL
Rated voltage 200V 17.5A IEC
Conductor cross section solid 0.2~1.5mm²
Pitch 3.5mm (accept customization )
Weight 10g(depends the contacts)
MOQ 100pieces
Brand OEM
Packing Natural packing or customization
Ambient temperature (operation) -40℃~105℃
Contact zone metal surface Tin-plated
Insulation Materials PA66



Product details of PCB Terminal Block 18P 3.5mm


Drawing of PCB Terminal Block  3.5mm



Packing of  PCB terminal block

According to Stardard Export Packing,Carton box, wooden box, wooden pallet etc

Shipping

- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- Port Ningbo port or Shanghai port
- By sea etc
