Doubled Level Pluggable Terminal Block

Sanan Electronics Technology Co., Ltd. has many years of experience in manufacturing professional terminal Connectors and other electronic component products.Doubled Level Pluggable Terminal Block is one of our impeccable connectors. Headquartered in Ningbo, China,the company currently has self-operated factory. we have been developing towards the goal of one-stop procurement, shortening the time and unit cost spent by customers on the procurement of we can customize electronic accessories to your specifications or use our extensive experience to help you find the right electronic component for your needs

Model:15EDGRH-3.5-14P

Send Inquiry    PDF DownLoad

Product Description


There are multiple kinds of terminal blocks , they all provide the same function of connecting electronical components in a safe, reliable manner,ideal for a variety of industrial control, automation, and test equipment applications,a terminal block is a tool used to safety connect two or more wires together, once the wires are properly arranged within a terminal block, current will be able to flow between the incoming and outgoing sources, terminal blocks promote the industry automation.

Feature

●Easy to use,no need to weld, handy and easy to assemble,solder in easily and tighten very well on the terminated wires, spiral wire is not easy to take off the line.
●Wide application, the terminal blocks is ideal foe small electronic watches, calculator, general computer, communication electronics device and other electronic equipment.
●Universal installation method, suitable for various situations
●PA66 material, sturdy, high temperature resistance, flame retardant.

Product specification of doubled level pluggable terminal block

Product name Doubled level pluggable terminal block
Material Plastic / copper
Color Green
Contact Form 4P-32P(accept customization )
Rated voltage 300V 8A UL
Rated voltage 250V 7A IEC
Pitch 3.5mm
Weight 8g(depends the contacts)
MOQ 100pieces
Brand OEM
Packing Natural packing or customization
Ambient temperature (operation) -40℃~105℃
Contact zone metal surface Tin-plated
Insulation Materials PA66

Application of doubled level pluggable terminal block



Product details of doubled level pluggable terminal block


Drawing



Packing of doubled level pluggable terminal block

According to Stardard Export Packing,Carton box, wooden box, wooden pallet etc

Shipping

- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- Port Ningbo port or Shanghai port
- By sea etc
