2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector
  • 2 In 2 Poles DIN Rail Terminal Quick Connector2 In 2 Poles DIN Rail Terminal Quick Connector

2 In 2 Poles DIN Rail Terminal Quick Connector

Sanan is a leading China 2 In 2 Poles DIN Rail Terminal Quick Connector manufacturers. DIN rail terminals can also be wired quickly? And reusable? It sounds unbelievable, Sanan can offer customers a DIN rail terminal quik connectors who have these advantages, and we a manufacture in China, providing high quality with competitive price, with deep experiences and our producing by automatic production techniques and equipments, we own many clients from all over the world, our Din rail termianl quik connectors are Widely used in distribution boxes, control cabinets, switchgear, plant, machinery, etc. We are looking forward to build cooperation partner with all friends and offer our quality service.

Send Inquiry

Product Description


Sanan is a leading China 2 In 2 Poles DIN Rail Terminal Quick Connector manufacturers. The DIN Rail Terminal Quick Connector is a reliable and efficient solution for your electrical wiring needs. Featuring a one-in one-out DIN Rail Spring Lever Terminal Block Electric Cable Wire Connector, this lever wire connector is easy to install and offers exceptional performance. With a wiring range of hard wire 0.08-4mm2 or less and soft wire 0.08-2.5mm2 or less, this terminal block conductor can handle a wide range of applications. Made from high-quality materials, including PA flame retardant engineering plastic and copper conductive strip, the DIN rail terminal quick connector ensures secure connections that provide optimal electrical performance. This compact wiring connector push-in terminal block is perfect for use in household appliances, lighting, machinery, and other wires.

Feature

●Built-in test point.
●No need for tools.
●Plug and play quick connecting.
●Low installed cost and safe operation.
●Different wire sizes and types can be combined in one connector.
●Can be mounted on the DIN rail which can simplify the wiring progress.
●Corrosion resistance, high-temperature resistance and wear resistance.v

Product specification of DIN Rail Terminal Quick Connector

Product name DIN Rail Terminal Quick Connector
Material Plastic PC
Color Red
Contact 4
Rated current 32A
Insulation Material 94V0
Gender Female
Certification CE ROSH
Voltage 250 Volts
Type Din rail
Brand OEM
Packing Natural packing or customization
Wire range 0.2-2.5mm²
AWG 28-14

Applicatin of DIN Rail Terminal Quick Connector



Product details of DIN Rail Terminal Quick


Packing of DIN Rail Terminal Quick

According to Stardard Export Packing,Carton box, wooden box, wooden pallet etc

Shipping

- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- Port Ningbo port or Shanghai port
- By sea etc


Hot Tags: 2 In 2 Poles DIN Rail Terminal Quick Connector, China, Manufacturers, Suppliers, Wholesale, Factory, Customized, Free Sample, Made in China, CE, Newest, Quality
